Unimer VC890C+
Во кошничка имате 0
парчиња.
|
Basic Function
|
Range
|
Basic accuracy
|
|
DC Voltage
|
200mV/2V/20V/200V/1000V
|
±(0.5%+3)
|
|
AC Voltage
|
2V/20V/200V/750V
|
±(0.8%+5)
|
|
DC Current
|
20uA/2mA/200mA/20A
|
±(0.8%+10)
|
|
200uA/20mA/200mA/20A
|
|
|
AC Current
|
2mA/200mA/20A
|
±(1.0%+15)
|
|
20mA/200mA/20A
|
|
|
Resistance
|
200Ω/2kΩ/20kΩ/200kΩ /2MΩ/20MΩ
|
±(0.8%+3)
|
|
200Ω/2kΩ/20kΩ/200kΩ/20MΩ
|
|
|
Capacitance
|
20nF/2uF/200uF
|
±(2.5%+20)
|
|
Celsius
|
(-40~1000)°C
|
|
|
Special Function
|
|
Diode
|
√
|
|
Transistor
|
√
|
|
Continuity buzzer
|
√
|
|
Low battery indication
|
√
|
|
Data Hold
|
√
|
|
Auto power off
|
√
|
|
Function protection
|
√
|
|
Restorable fuse protection
|
√
|
|
Shockproof protection
|
√
|
|
Input impedance
|
10MΩ
|
|
Sampling rate
|
3 times/s
|
|
AC Frequency response
|
40~400Hz
|
|
Operation way
|
Manual range
|
|
Max. Display
|
1999
|
|
LCD size
|
55×43mm
|
|
Battery
|
9V (6F22)
|
|
Product color
|
Case: dark gray; Holster color : yellow
|
|
Product Net Weight
|
Approx:270g
|
|
Product Dimension
|
168×87×47mm
|
|
Standard Accessories
|
Test leads/batteryinstruction manual/TP01
|
|
temperature probe(with temperature function)/Testing accessories
|
|
Standard inner packing
|
Color box
|
|
Standard Quantity Per Carton
|
30 pcs
|
|
Carton size
|
405×350×450mm
|
|
Standard Gross Weight
|
Approx:25kg
|
