Lemna stanica Jovy Systems RE-8500

• BGA rework Multiple profiling options (standard lead-free, standard leaded and user define).
- • Wide lower heating area (500mmx 450mm).
- • Five channels thermocouple real time temperature reading.
- • Process & profile analyzer for complete process study and control.
- • Accurate temperature readings of +/- 2°C.
- • Alarm set point to increase the process safety and control.
- • Equipped with many types of reflectors for focusing and spotting the upper heater heating area.
• Password protection for data and settings lock.
• High ramp preheating and reflow up to 2.5°C/sec.
• Optimum heating with 3 controlled heating zones.
• Ideal application cooling phase in two methods optionally direct and indirect air flow, adjustable airflow power fan.
• All Windows multi lingual OS.
Specifications

Dimensions L x W x H	520mm x 600mm x 310mm
Working depth	220 mm
Power supply	230 V AC, 50/60 Hz,16 A
Installed heating power	Total 3600 Watt. Upper heater power is 600W & Lower heaters power are 3000W
Upper heater size	60mm x 120 mm one zone
Bottom heater size	340mm x 280mm ,2 separate heating zones
Distance of Upper heater to PCB	Standard is 60 mm , range from 30mm to 80mm
Distance of Lower heater to PCB	35 mm
Temperature sensor channels	5 x k-type thermocouple (potential free) 2 main and 3 optional
Maximum component size PL	120mm x 60 mm
Control	via PC with Jovy control room USB 2.0
Operating Systems	Windows XP® or Windows Vista® Windows7®
